가스유량계
가스유량계
다음S431 OEM V2
- 제조사 : SUTO iTEC Co. Limited
- 제조국 : Germany
•마모성 부품이 없어 고온 및 진동에 강함
•용접니플을 이용한 편리한 설치
•모바일 앱(S4C-FS) 설치를 통한 원격세팅 및 모니터링
•V1 대비 컴팩트한 사이즈
•수직, 수평 파이프 모두 적용 가능
•용접니플을 이용한 편리한 설치
•모바일 앱(S4C-FS) 설치를 통한 원격세팅 및 모니터링
•V1 대비 컴팩트한 사이즈
•수직, 수평 파이프 모두 적용 가능
DOWNLOAD
제품사양
Measurement | |
Flow |
|
Accuracy | 1.5 % o.RDG ±0.3 % FS |
Selectable units |
|
| Volumetric Flow | m³/h, m³/min, l/min, l/s, cfm |
| Mass Flow | kg/h, kg/min, kg/s, t/h, lb/h |
| Actual Velocity | m/s, f t /min |
| Measuring range | see table below |
| Repeatability | 0.5 % o.RDG |
| Sensor | Differential pressure sensor with pitot tube |
| Sampling rate | 3/sec |
| Turndown ratio | 10:1 |
| Response time (t90) | 2 sec |
| Consumption | |
| Selectable units | m³, ft³, t, lb, l, kg |
| Pressure | |
| Accuracy | 0.5 % FS |
| Selectable units | bar, psi, kPa, MPa |
| Measuring range | 0...1.6 MPa(g) |
| Sensor | Piezzo resistive sensor |
| Temperature | |
| Accuracy | 0.5 °C |
| Selectable units | °C, °F |
| Measuring range | -40...+120 °C |
| Sensor | Pt1000 |
| Reference conditions | |
| Selectable conditions | 20 °C 1000 mbar (ISO1217) 0 °C 1013 mbar (DIN1343) freely adjustable |
| Signal / Interface & Supply | |
| Analog output | |
| Signal | 4...20 mA, isolated |
| Scaling | 0...max flow |
| Load | 250R |
| Update rate | 1/sec |
| Pulse output | |
| Signal Scaling | Max 30V, 200 mA |
| Scaling | 1 pulse per consumption unit |
| Fieldbus | |
| Protocol | Modbus/RTU |
| Supply | |
| Voltage supply | 12...36 VDC |
| Current consumption | 60 mA, 1.5 W |
| General data | |
| Configuration | |
| Wireless | S4C-FS APP for mobile phones |
| Material | |
| Process connection | Stainless steel 1.4404 (SUS 316L) |
| Housing | PC + ABS |
| Sensor | Stainless steel 1.4404 (SUS 316L) |
| Miscellaneous | |
| Electrical connection | 1 x M12 (5 pole) |
| Protection class | IP65 |
| Approvals | CE, RoHS, FCC |
| Process connection | M32 x 1.5 welding nipple |
| Weight | 1.7 kg |
| Operating conditions |
|
| Medium | Wet/dry air, other gases |
| Medium quality | non corrosive |
| Medium temperature | -20...+120 °C |
| Medium humidity | no requirements |
| Operating pressure | 0...1.6 MPa(g) |
| Ambient temperature | -20...+85 °C |
| Ambient humidity | < 95 % rH |
| Storage temperature | -30...70 °C |
| Transport temperature | -30...70 °C |
| Pipe sizes | >=DN50 |
Flow Ranges | |||||||
Tube | Volumetric Flow | ||||||
Inch | mm | m³/h | m³/min | cfm | |||
|
| Min | Max | Min | Max | Min | Max |
| 2" | 53.1 | 121 | 1,298 | 2.0 | 21.6 | 71 | 764 |
| 2½” | 68.9 | 206 | 2,218 | 3.4 | 37 | 121 | 1,305 |
| 3" | 80.9 | 287 | 3,084 | 4.8 | 51 | 169 | 1,815 |
| 4" | 100 | 443 | 4,760 | 7.4 | 79 | 261 | 2,802 |
| 5" | 125 | 697 | 7,500 | 11.6 | 125 | 410 | 4,414 |
| 6" | 150 | 1,009 | 10,853 | 16.8 | 181 | 594 | 6,387 |
| 8" | 200 | 1,812 | 19,482 | 30.2 | 325 | 1,066 | 11,465 |
| 10" | 250 | 2,833 | 30,465 | 47.2 | 508 | 1,667 | 17,929 |
| 12" | 300 | 4,079 | 43,870 | 68 | 731 | 2,401 | 25,818 |
