공기분석장치

공기분석장치

S601 Stationary Compressed Air Purity Analyzer

  • 제조사 : SUTO iTEC Co. Limited
  • 제조국 : Germany
•입자농도(Particle concentration) 측정
•유증량(Oil vapor) 측정
•노점, 압력 측정
•6mm quick connector로 Compressed air 연결
DOWNLOAD
제품목록

제품사양

 Measurement

  General data

 Particle concentration

 Configuration

 Counting efficiency





 According ISO 21501-4

 Option A1263:                     Option A1260:

 30 ... 70 % of d > 0.1 μm         30 ... 70 % of d > 0.3 μm

 90 ... 110 % of d ≥ 0.3 μm      90 ... 110 % of d ≥ 0.45 μm


 Others


 Device comes pre-configured

 Configuration can be done via on-screen touch

 Display
 Integrated Touchscreen, Size: 5“, Resolution: 800 x 480 px
 Data Logger

 Selectable units

 cn/m³, cn/ft³

 Storage






 100 mio. values






 Measuring range





 Option A1263:              Option A1260:

 0.1 < d ≤ 0.5 μm            0.3 < d ≤ 0.5 μm

 0.5 < d ≤ 1.0 μm            0.5 < d ≤ 1.0 μm

 1.0 < d ≤ 5.0 μm            1.0 < d ≤ 5.0 μm

 5.0 μm < d                      5.0 μm < d

 Sensor

 Laser optical particle counter Material

 Sampling rate

 1 min. Process connection

 Brass nickel-plated, FKM

 Flow rate

 2.83 l/min Housing

 Sheet steel, powder coated cabinet

 Pressure Dew Point

 Miscellaneous

 Accuracy



 ± 1 °C Td (0 ... 20 °C Td)

 ± 2 °C Td (-70 ... 0 °C Td)

 ± 3 °C (-100 ... -70 °C Td)

 Electrical connection



 AC Clamp Terminals, M12, RJ45



 Selectable units

 °C, °F

 Protection class

 IP54 (cover lid closed)

 Measuring range

 -100 ... +20 °C Td

 Approvals

 CE

 Sensor



 QCM + Polymer



 Process connection



 Micro quick connector,

 full passthrough,

 male (1.5 m hose with coupling included)

 Response time (t90)



 -20 °C Td -> -60 °C Td = < 240 sec

 -60 °C Td -> -20 °C Td = < 30 sec

 @ 4 l/min

 Weight



 15 kg



 Oil vapor

 Operating conditions

 Accuracy


 5 % of value +/- 0.003 mg/m³


 Medium


 Compressed Air, Nitrogen N₂,

 Carbon dioxide CO₂ (software setting)

 Detection limit

 0.003 mg/m³

 Medium quality

 ISO 8573-1: 4.4.4 or better

 Resolution

 0.001 mg/m³

 Medium temperature

 0 ... + 40 °

 Selectable units

 mg/m³

 Medium humidity

 Medium humidity < 40 % rH, no condensation

 Measuring range

 0.001 ... 5.000 mg/m³

 Operating pressure

 0.3 ... 1.5 MPa(g)

 Sensor

 PID (Photoionisation detector)

 Ambient temperature

 0 ... +50 °C

 UV lamp lifetime


 1 year or 6000 working hours,

 whichever comes first

 Ambient humidity


 0 ... 90 % rH


 Sampling rate

 1 sec.

 Storage temperature

 -10 ... + 70 °C

 Pressure

 Transport temperature

 -10 ... + 70 °C

 Accuracy

 0.5 % FS



 Measuring range

 0.1 ... 1.6 MPa(g)

 Sensor

 Piezo resistive sensor

 Temperature

 Accuracy

 ± 0.3 °C

 Measuring range

 -30 ... +70 °C

 Sensor

 Pt100

 Reference conditions

 Selectable conditions

 ISO1217 20 °C 1000 mbar



 Signal / Interface & Supply

 Fieldbus

 Protocol

 Modbus/TCP

 Update rate

 1 / sec.

 Alarm output

 Relay

 2 x Changeover Relay (freely programmable)

 Rating

 230 VAC, 3A

 Power Supply

 Voltage supply

 100 ... 240 VAC, 50/60 Hz

 Current consumption

 50 VA

 Interface

 USB

 USB Micro with OTG support
