Measurement

 Particle concentration

 Accuracy

 Counting Efficiency according

 ISO 21501-4

 30 ... 70 % of d > 0.1 μm

 90 ... 110 % of d ≥ 0.3 μm

 Others

 Device comes pre-configured

 Configuration can be done via on-screen touch

 Selectable units

 cn/m³, cn/ft³

 Storage

 Up to 3 million recorded data sets

 (10 channels each)

 Measuring range

 0.1 < d ≤ 0.5 μm

 0.5 < d ≤ 1.0 μm

 1.0 < d ≤ 5.0 μm

 5.0 μm < d

 Integrated report generator for PDF export

 Sensor

 Laser optical particle counter

 Sampling rate

 1 min.

 Brass nickel-plated, FKM

 Flow rate

 2.83 l/min

 PC + ABS, Al alloy

 Pressure Dew Point

 Accuracy

 ± 1 °C Td (0 ... 20 °C Td)

 ± 2 °C Td (-70 ... 0 °C Td)

 ± 3 °C (-100 ... -70 °C Td)

 Electrical connection

 2-Pin, push-pull socket

 Selectable units

 °C, °F

 IP54 (cover lid closed)

 Measuring range

 -100 ... +20 °C Td

 CE

 Sensor

 QCM + Polymer

 Process connection

 Micro quick connector,

 full passthrough,

 male (1.5 m hose with coupling included)

 Response time (t90)

 -20 °C Td -> -60 °C Td = < 240 sec

 -60 °C Td -> -20 °C Td = < 30 sec

 @ 4 l/min

 Weight

 9.8 kg

 Oil vapor

 Accuracy

 5 % of value +/- 0.003 mg/m³

 Medium

 Compressed Air, Nitrogen N₂,

 Carbon dioxide CO₂ (software setting)

 Detection limit

 0.003 mg/m³

 ISO 8573-1: 4.4.4 or better

 Resolution

 0.001 mg/m³

 0 ... + 40 °

 Selectable units

 mg/m³

 Medium humidity < 40 % rH, no condensation

 Measuring range

 0.001 ... 5.000 mg/m³

 0.3 ... 1.5 MPa(g)

 Sensor

 PID (Photoionisation detector)

 0 ... +50 °C

 UV lamp lifetime

 1 year or 6000 working hours,

 whichever comes first

 Ambient humidity

 0 ... 90 % rH

 Sampling rate

 1 sec.

 -10 ... + 70 °C

 Pressure

 -10 ... + 70 °C

 Accuracy

 0.5 % FS

 Measuring range

 0.1 ... 1.6 MPa(g)

 Sensor

 Piezo resistive sensor

 Temperature

 Accuracy

 ± 0.3 °C

 Measuring range

 -30 ... +70 °C

 Sensor

 Pt100

 Reference conditions

 Selectable conditions

 ISO1217 20 °C 1000 mbar

 Signal / Interface & Supply

 Fieldbus

 Protocol

 Modbus/TCP

 Update rate

 1 / sec.

 Power Supply

 Voltage supply

 Mains supply adapter (AC/DC)

 Input: 100 ... 240 VAC, 50/60 Hz, 1.4 A

 Output: 24 VDC, 2.5 A, 60 W max

 Current consumption

 1.4 A

 Interface

 USB

 USB Micro with OTG support

 LTE/4G USB

 USB Port for 4G/LTE Modem
