Technical specification

 Ambient temperature

 Max. 95°C

 Maximum pressure

 For 25°C

 For 95°C

 4 MPa

 1.5 MPa

 Cable

 CNP–18N

 CNP–18F

 PVC 2x 0.75 mm2

 (Screw connector)

 Insulation bushing

 PTFE (Polytetrafluorethylene)

 Protection class (CNP–18N)

 IP67

 Housing material

 St. steel W.Nr. 1.4305 (AISI 303)

 Weight

 Approx. 100 g
