레벨스위치
VKS00, VK604 / 플로트형
- 제조사 : SIKA Dr. Siebert & Kühn GmbH & Co. KG
- 제조국 : Germany
•Stainless steel male threaded adapters
•쉬운 설치방법
•쉬운 설치방법
DOWNLOAD
제품사양
| Technical data | |
| Switching function | Contact → opens with falling level → closes with rising level reversing possible |
| Activation point, related to middle axis (water, 20 °C) |
-4...0 mm
|
| Hysteresis | Approx. 1...4 mm |
| Pressure rating | PN 10 |
| Minimum medium density | 0.78 kg / dm³ |
| Temperature ranges | |
| Medium | -10...100 °C |
| Ambient → VKS → VK6 |
-25...80 °C |
| Electrical data | |
|
Electrical connection
→ VK6 |
Plug connector
1.5 m PVC jacket cable |
| Max. switching current | 1 A |
| Max. switching voltage | 230 VAC, 48 VDC |
| Max. rating | 26 VA, 20 W |
| Degree of protection EN 60529 |
IP65
|
| Protection class EN 60730-1 | Class II |
| Options | |
| For type | See order code |
|
VKS
|
→ Plug connector DIN EN 175301-803-A incl. cable socket with 2 LEDs for switching voltages 24 V...230 V AC / DC ±20 %, ambient temperature -20...70 °C → or 4-pin sensor plug M12 x 1 |
