레벨스위치
제품사양
| Technical specifications | |
| Range of ambient operational temperatures | -20 ... +60°C, the float should be protected against freezing (see Maintenance and operational conditions) |
| Range of the sensed medium densities | 800 ... 950 kg/m3 |
| Minimum layer thickness of medium for detection - on water level - in empty reservoir |
5 mm 25 mm |
| Cable | PUR 3x0.14 mm2 (brown: + pole, white: - pole, green: not used) |
| Float weight (board + 4 floats + CPS-24Xi sensor) | 600 g |
| Working area | With spark resistant power supply unit NSSU-811-230V(24V)-R SP2, complete float system zone 1 |
| Other parameters | see manual for CPS-24Xi sensor see manual for NSSU-811 sensor |
