Measurement

 General data

 Flow

 Configuration

 Accuracy

 1.5 % o.RDG ±0.3 % FS

 Wireless

 S4C-FS App for mobile phones

 Selectable units

 l/min, cfm, kg/h, m3/h

 PC Software

 Measuring range

 see table on the previous page

 Display

 Repeatability

 0.5 % o.RDG

 Integrated

 Sensor

 Thermal mass flow sensor

 Data Logger

 Sampling rate

 10/sec

 Storage

 8 Mio. values

 Turndown ratio

 100:1

 Material

 Response time (t90)

 0.5 sec

 Process connection

 Aluminum alloy

 Consumption

 Housing

 Selectable units

 Sensor

 Ceramic, glass coated

 Pressure

 Metal parts

 Aluminum alloy

 Accuracy

 0.5 % FS

 Miscellaneous

 Selectable units

 bar, psi

 Electrical connection

 2 x M8 (4 pole

 Measuring range

 0 ... 10 bar(g)

 Protection class

 IP54

 Sensor

 Piezo resistive sensor

 Approvals

 CE, RoHS, FCC

 Reference conditions

 Process connection

 G-thread

 Selectable conditions

 20 °C 1000 mbar (ISO1217)

 0 °C 1013 mbar (DIN1343)

 freely adjustable

 Weight

 0.45 ...  1.3 kg (depends on model)

 Signal / Interface & Supply

 Operating conditions

 Analog output

 Medium

 Signal

 4 ... 20 mA, isolated

 Medium quality

 ISO 8573: 4.4.3 or better

 Scaling

 0 ... max flow freely adjustable

 Medium temperature

 Load

 Max 250 Ω

 Medium humidity

 < 90 % rH, no condensation

 Update rate

 3/sec

 Operating pressure

 Pulse output

 Ambient temperature

 0 ... 50 °C

 Signal

 Switch output normally open

 max 30 VDC, 200 mA

 Ambient humidity

 < 95 % rH

 Scaling

 1 pulse per consumption unit

 Storage temperature

 -30 ... 70 °C

 Fieldbus

 Transport temperature

 -30 ... 70 °C

 Protoco

 Pipe sizes

 Supply

 Voltage supply

 Current consumption
