전자유량계
EX800
- 제조사 : SeaMetrics Incorporated
- 제조국 : U.S.A
•삽입형의 전자유량계
•적용배관 사이즈: 1"~12"
•설치가 용이하며, 유지보수가 간편함
•적용배관 사이즈: 1"~12"
•설치가 용이하며, 유지보수가 간편함
DOWNLOAD
제품사양
| Specifications | |||
| Pipe Size | 1” to 12” | ||
| Power | Full Power: 12 - 24 Vdc, 250mA Low Power: 12 - 24 Vdc, 40mA average with 250mA peaks | ||
|
Materials
|
Housing | Powder-coated cast aluminum | |
| Sensor Body | 316 Stainless Steel, Brass, or PVC | ||
| O-ring | EPDM (Viton® optional) | ||
| Electrodes | Hastelloy | ||
| Electrode Cap | PVDF (Kynar®) | ||
|
Maximum Pressure
|
Brass/Stainless Steel | PVC (See Pressure vs. Temp. Chart) | |
| 200 psi (14 bar) | 150 psi (10 bar) @ 75˚ F (24˚ C) | ||
|
Temperature
|
Ambient | 0˚ to 160˚ F (-17˚ to 72˚ C) | 0˚ to 160˚ F (-17˚ to 72˚ C) |
| Fluid | 32˚ to 200˚ F (0˚ to 93˚ C) | 32˚ to 130˚ F (0˚ to 55˚ C) @ 0 psi | |
| Minimum Conductivity | 20 microSiemens/cm | ||
| Flow Velocity | 0.28 to 20 ft/sec (0.08 - 6.09 m/sec) | ||
| Accuracy | ± 1% of full scale | ||
| Output | Square wave pulse, opto-isolated, 500 Hz @ 20 ft/sec | ||
| Empty Pipe Detection | Software, defaults to zero flow | ||
|
Cable
|
Standard 18’ (6m), #22 shielded twisted pair, 4-conn. Max. cable run at 24 Vdc = 1000’ (300m); at 12 Vdc = 500’ (150m). For other circumstances, contact the factory. | ||
| Regulatory | CE Mark | ||
|
Flow Range |
Nominal |
1” |
1½” |
2” |
3” |
4” |
6” |
8” |
10” |
12” |
|
Min GPM |
.69 |
1.5 |
2.7 |
6.2 |
11 |
25 |
43 |
68 |
99 | |
|
Max GPM |
49 |
110 |
196 |
440 |
783 |
1760 |
3130 |
4900 |
7050 |
