노점센서

노점센서

S211 / Dewpoint sensor for compressed air and gases (-60 ... +20 °C Td)

  • 제조사 : SUTO iTEC Co. Limited
  • 제조국 : Germany
•컴팩트한 사이즈
•디스플레이 옵션 (340도 회전가능)
•4...20mA + Modbus 출력가능
•IP65 등급 (방진방수)
•°C Td, g/m³, mg/m³, ppmv, g/kg 등의 단위변환가능
DOWNLOAD
제품목록

제품사양

 Measurement Ranges and Applications

 Model

 S211

 S215

 S220

 Dew point

 -60 ... +20 °C Td

 -20 ... +50 °C Td

 -100 ... +20 °C Td

 Temperature

 -30 ... +70 °C

 -30 ... +70 °C

 -30 ... +70 °C

 Pressure

 0 ... 1.6 MPa

 0 ... 1.6 MPa

 0 ... 1.6 MPa

 Application


 In desiccant dryers


 In fridge dryers


 In high tech requirements and

 conditions



 Specifications

 Model

 S211

 S215

 S220

 Measurement Range



 Dew point         -60 ... +20 °C Td

 Temperature     -30 ... +70 °C

 Pressure             0 ... 1.6 MPa

 Dew point         -20 ... +50 °C Td

 Temperature     -30 ... +70 °C

 Pressure             0 ... 1.6 MPa

 Dew point         -100 ... +20 °C Td

 Temperature     -30 ... +70 °C

 Pressure             0 ... 1.6 MPa

 Dew point sensor

 Polymer

 Polymer

 Polymer + QCM

 Operating Pressure


 -0.1 ... 1.6 MPa

 -0.1 ... 35.0 MPa optional

 -0.1 ... 1.6 MPa

 -0.1 ... 35.0 MPa optional

 -0.1 ... 1.6 MPa


 Response time (t90)@4 l/min


 0 °C Td ➞ -60 °C Td ≤ 280 sec

 -60 °C Td ➞ 0 °C Td ≤ 65 sec

 0 °C Td ➞ -20 °C Td ≤ 50 sec

 -20 °C Td ➞ 0 °C Td ≤ 35 sec

 0 °C Td ➞ -80 °C Td ≤ 420 sec

 -80 °C Td ➞ 0 °C Td ≤ 90 sec

 Accuracy

 Dew point           +/- 1 °C Td (0 ... 20 °C Td)

                             +/- 2 °C Td (-70 ... 0 / +20 ... +50°C Td)

                             +/- 3 °C Td (-100 ... -70 °C Td)

 Temperature       +/- 0.3 °
 Pressure              0.5 % FS

 Process connection

 G 1/2” (ISO 228/1), stainless steel 1.4301 (SUS 304)

 Operating conditions

 Medium Temp.: -30 ... +70 °C / Ambient Temp. : 0 ... +50 °C / Ambient Humidity: 0 ... 100 % rH

 Materials

 Casing: Aluminum alloy / Process thread: Stainless steel 1.4301 (SUS 304) / Display cover: PC + ABS

 Classification / Approval

 IP65 / CE

 Sensor protection

 Sinter filter (stainless steel)

 Transport & Storage

 Transport Temperature: -30 ... + 70 °C / Storage Temperature: -20 ... + 50 °C

 Weight

 180 g

 Measured gases (Medium)

 Air, Argon, O₂, N₂, CO₂*

 Output Signal

 4 ... 20 mA 2-wire + SDI, 4 ... 20 mA 3-wire + SDI, 4 ... 20 mA 3-wire + Modbus/RTU

 Sensor types

 Temperature sensor: Pt100 / Pressure sensor: Piezo resistive type

 Display option

 0.66” OLED display, indicates the measured value and unit

 Supply Voltage

 15 ... 30 VDC


* CO2 medium:

If the S211 is used in CO2 the range is limited to -40 °C Td

The S211 and S220 must be set to CO2 ex works or by using the S4C-DP Service Software + Service Kit

(please state at the order if S211 and S220 will be used in CO2)
