임펠러유량계
SES
- 제조사 : SeaMetrics Incorporated
- 제조국 : U.S.A
•케미컬 유체에 호환
•Low flow monitoring
•Stainless steel body
•Low flow monitoring
•Stainless steel body
DOWNLOAD
제품사양
| Specifications* | ||
| Connection Ports | 1/2”, 3/4”, 1” —Female NPT thread | |
| Sensor Cable | 18 ft (6 m) standard—maximum cable run 2000 ft (607 m) | |
|
Materials
|
Body | 316 stainless steel |
|
Rotor |
PVDF (Kynar®)—2 magnet (6 magnet high resolution optional) | |
|
Shaft |
Nickel-bonded tungsten carbide (ceramic or silicon carbide optional) | |
| O-Ring | Teflon®-coated Viton® (Viton® or EDPM optional) | |
| Bearings | Ruby ring and ball | |
| Cover | 316 stainless steel | |
| Maximum Temperature | 200˚ F (93˚ C) | |
| Maximum Pressure | 500 psi (35 bar) | |
| Accuracy | ±1% of full scale | |
|
Power
|
Standard | 6–36 Vdc, < 2 mA |
| Micropower | 3.1–16 Vdc, 60 μA @ 3.6 Vdc (for FT450 and DL76 only) | |
| Outputs | Current sinking pulse, 6–24 Vdc | |
* Specifications subject to change. Please consult our website for current data (seametrics.com)
Kynar is a registered trademark of Arkema, Inc., Teflon and Viton are registered trademarks for DuPont Corporation
Flow Range
|
Model # |
K-Factor* |
Gal/Min |
Liter/Min |
|
-050 |
535 |
0.1-10 |
0.38-38 |
|
-075 |
390 |
0.2-15 |
0.75-57 |
|
-100 |
220 |
0.5-25 |
1.9-95 |
* Nominal K-factors (based on averages) for standard 2-magnet SPT and SPX.
High resolution (6-magnet) K-factors are approximately tripled.
