General Specifications

 Measurement range

 Dew point           -100 ... 0 °C Td

 Temperature       -30 ... +70 °C

 Pressure              -0.1 ... 1.6 MPa

 Dew point sensor

 QCM

 Temperature sensor

 Pt100

 Pressure sensor

 Piezo resistive type

 Accuracy

 Dew point           ±2 °C Td

 Temperature        0.3 °C

 Pressure               0.05 bar

 Operating Pressure

 -0.1 ... 1.6 MPa

 Operating Temperature (Medium)

 -30 ... +70 °C

 Measured gases (Medium)

 Air, Argon, O2, N2, CO2*

 Response Time t90 (@ 4 l/min)

 -80 °C Td -> -20 °C Td = 20 sec

 -20 °C Td -> -80 °C Td =180 sec

 Ambient Temperature

 0 ... +50 °C

 Ambient Humidity

 0 ... 100 % rH

 Supply Voltage

 12 ... 30 VDC

 Current consumption (model depending)

 30 mA @ 24 VDC 3-Wire

 20 mA @ 24 VDC 2-Wire

 Output signals (model depending)

 4 ... 20 mA 3-Wire

 4 ... 20 mA 2-Wire

 Modbus/RTU

 Electrical connection

 M12, 5 poles

 Process connection

 G 1/2“ thread (ISO 228/1)

 Stainless steel 1.4301 (SUS 304)

 Casing material

 Zinc alloy

 Classification

 IP65

 EMC

 IEC 61326-1

 Approval

 -

 Sensor protection

 Sinter filter/perforated cap

 Transport Temperature

 -30 ... +70 °C

 Storage Temperature

 -20 ... +50 °C

 Weight

 204 g
