SIGNAL 4.0
- 제조사 : meister
- 제조국 : Germany
•Analog output (4-20 mA and 0-10 V)
제품사양
| OPERATING DATA | |
| Accuracy | ± 1%(1) |
| Operating temperature | -20 °C - 70 °C |
| Storage temperature | -20 °C - 80 °C |
| Repeatability | tbd. |
(1) The actual accuracy depends on the flow sensor used. On request the accuracy of the flow sensor used can be significantly increased by a customized calibration.
POSSIBLE COMBINATIONS | ||
Type Sensor | Transmitter | Combination |
DUM | + SIGNAL 4.0 | = DUM/SIGNAL 4.0 |
DUM/A | + SIGNAL 4.0 | = DUM/A/SIGNAL 4.0 |
DWM | + SIGNAL 4.0 | = DWM/SIGNAL 4.0 |
DWM/A | + SIGNAL 4.0 | = DWM/A/SIGNAL 4.0 |
RVM/U-1 | + SIGNAL 4.0 | = RVM/U-1/SIGNAL 4.0 |
RVM/UA-1 | + SIGNAL 4.0 | = RVM/UA-1/SIGNAL 4.0 |
RVM/U-2 | + SIGNAL 4.0 | = RVM/U-2/SIGNAL 4.0 |
RVM/UA-2 | + SIGNAL 4.0 | = RVM/UA-2/SIGNAL 4.0 |
RVM/U-4 | + SIGNAL 4.0 | = RVM/U-4/SIGNAL 4.0 |
WY | + SIGNAL 4.0 | = WY/SIGNAL 4.0 |
|
|
|
DKM-1 | + SIGNAL 4.0 | = DKM/-1/SIGNAL 4.0 |
DKM/A-1 | + SIGNAL 4.0 | = DKM/A-1/SIGNAL 4.0 |
DKM-2 | + SIGNAL 4.0 | = DKM/-2/SIGNAL 4.0 |
DKM/A-2 | + SIGNAL 4.0 | = DKM/A-2/SIGNAL 4.0 |
DKME-1 | + SIGNAL 4.0 | = DKME-1/SIGNAL 4.0 |
DKME/A-1 | + SIGNAL 4.0 | = DKME/A-1/SIGNAL 4.0 |
|
|
|
DWM-L | + SIGNAL 4.0 | = DWM-L/SIGNAL 4.0 |
DWM/A-L | + SIGNAL 4.0 | = DWM/A-L/SIGNAL 4.0 |
RVM/U-L1 | + SIGNAL 4.0 | = RVM/U-L1/SIGNAL 4.0 |
RVM/U-L2 | + SIGNAL 4.0 | = RVM/U-L2/SIGNAL 4.0 |
RVM/U-L4 | + SIGNAL 4.0 | = RVM/U-L4/SIGNAL 4.0 |
| ELECTRICAL DATA | |
| Analog output | 4...20 mA and 0...10 V |
| Power supply | 24 VDC (19...30 VDC) |
| Power consumption | < 1 W |
| Current output | Max. load 600 Ω |
| Voltage output | Max. current 10 mA |
| Connection | For round plug M12x1, 5 pin |
|
Ingress Protection
| IP 65 IP 67 |
