Technical data

 Display

 6-digit, 14-segment LED display, red, 14 mm character height

 Programming

 Using front keys or by teach-in function

 Signal input

 Frequency signal from flow or volume sensor

 Outputs

 2 x relays with change-over contact

 → Switching voltage

 Max. 250 VAC/150 VDC

 → Switching current

 Max. 3 A AC/DC, min. 30 mA DC

 → Switching capacity

 Max. 750 VA/90 W

 Operating temperature

 -20 °C...65 °C

 Storage temperature

 -25 °C...75 °C

 Housing material

 Polycarbonate UL94 V-2

 Protection class EN 60529

 IP65 (front side)

 Protection class EN 60730-1

 Class II

 Voltage supply (sensor)

 (AC version): 24 V DC (±15 %), 80 mA (DC version): Max. 80 mA, connected voltage supply is looped through

 Power supply

 100...240 V AC (±10 %), max. 11 VA, 50/60 HZ or 10...30 V DC, max. 5.5 W
