Function

 2/2 NC proportional

 Pneumatic connection

 cartridge

 Electrical connection

 flying leads, 70 – 80 mm

 Media type

 air, oxygen, inert gases

 Media quality

 ≤ 10 µm

 Orifice

 1.0 mm

 Operating pressure

 0...10 bar(g) / 0...145 psig

 Max. flow (air | @ 10 bar(g) | @ 20 °C)

 up to 72 ls/min

 Flow coefficient Kv

 up to 0.030 m 3 /h

 Temperature range, ambient

 5 °C to 50 °C

 Temperature range, media

 5 °C to 50 °C

 Temperature range, storage

 -40 °C to 80 °C

 Internal leakage @ pmax

 < 1 ml/min

 External leakage @ pmax

 < 1 ml/min

 Current range

 0 to 200 mA

 Nominal coil resistance @ 20 °C

 60.5 Ω

 Recommended open-circuit voltage

 24 V

 Nominal power consumption @ 20 °C

 max. 2.5 W

 Thermal resistance (without flow)

 approx. 45 K/W

 Duty cycle (without flow)

 100 % @ I < 155 mA

 Weight

 23 g

 Current hysteresis

 < 8 % of max. current

 Mounting position

 Any direction
