Basic technical data

 Working environment (EN 60079-10-1)

 no explosive hazard area

 Supply voltage

 HLM–35_–_ _- _- I- _ - _ _ _ _

 HLM–35_–_ _- _- U- _ - _ _ _ _

 12 ... 34 V DC

 12 ... 34 V DC

 Current output

 Voltage output

 HLM–35_–_ _- _- I- _ - _ _ _ _

 HLM–35_–_ _- _- U- _ - _ _ _ _

 4 ... 20 mA

 0 ... 10 V

 Consumption (empty voltage output)

 HLM–35_–_ _- _- U- _ - _ _ _ _

 max. 8 mA

 Permissible overload

 1.5x of range

 Basic accuracy (non-linearity, hysteresis, repeatability)

 0.5% of range

 Long-term stability

 0.3 % / year

 Temperature error for zero and range between 0 ... +50°C

 max. 0.04% / K

 Temperature compensation range

 0 ... +50°C

 Operating temperature range (temperature of the media)

 -20 ... +70 °C

 Max. load resistance for current output (at U = 24 V DC)

 Rmax= 600 Ω

 Min. load resistance for current output

 Rmin= 1 kΩ

 Protection class

 type HLM–35_–_ _- _- _- C- _ _ _ _

 type HLM–35_– _- _- _- (A,B,V,H)- _ _ _ _

 IP67

 IP68

 Cable

 type HLM–35_–_ V- _- I- _- _ _ _ _

 type HLM–35_–_ V- _- U- _- _ _ _ _

 type HLM–35_–_ K- _- I- _- _ _ _ _

 type HLM–35_–_ K- _- U- _- _ _ _ _

 PVC 2 x 0.75 mm2

 PVC 3 x 0.5 mm2

 PE 2 x 0.25 mm2  with capillary

 PE 3 x 0.25 mm2  with capillary

 Weight

 sensor

 cable (1 m)

 190 g

 60 g
