Technical specification (variants N, NT)

 Supply voltage

 CLM – 36N(T)–_ _–_–I

 CLM – 36N(T)–_ _–_–U

 9 ... 36 V DC

 16 ... 36 V DC

 Current output

 Voltage output

 4 ... 20 mA

 0 ... 10 V *

 Power consumption (off-load) CLM–36N(T)–_ _–_–U

 approx. 8mA

 Sensitivity ranges

 20; 30; 50; 100; 150; 300; 500; 1000 pF

 Initial capacity regulation ratio

 min. 1:2

 Nonlinearity

 max. 1 %

 Temperature error

 max. 0,05% / K

 Voltage error for current and voltage output

 max. 0,3 μA/V and 0,1 mV/V

 Internal resistance / Electric strength (Electrode – Housing)

 1 MΩ / 250 V AC

 Coupling capacity / Electric strength (Housing – Supply leads)

 51 nF / 250 V AC

 Protection class

 Optional (Connector GAN-DADE 7A / DAEE 7A)

 IP67 (Housing), IP65 (Connector) IP67

 Maximal load (serial) resistance for current output (U = 24 V)

 Rmax= 750 Ω

 Minimal load resistance for voltage output

 Rmin> 1 kΩ

 Maximum tensile strength of the rope electrode

 1400 kg

 Recommended cable

 PVC 2x0,75 mm2 (3x0,5 mm2)

 Weight (exclude electrode)

 Version N, Xi

 Version NT, XiT

 approx. 0,5 kg

 approx. 1 kg
