Basic technical data

 Supply voltage

 DLM – 35N(T)–_ _–_–I

 DLM – 35N(T)–_ _–_–U

 9 ... 34 V DC

 12 ... 34 V DC

 Current output

 Voltage output

 4 ... 20 mA (2-wire)

 0 ... 10 V (3-wire)

 Power consumption

 DLM–35_–_ _–_–I

 DLM–35_–_ _–_–U

 3.75 ... 20.5 mA

 5 mA (voltage output open circuit)

 Non-linearity

 max. 1 %

 Temperature error

 max. 0.05% / K

 Voltage error for current and voltage output

 max. 0.3 μA/V and 0.1 mV/V

 Leakage resistance (electrode - housing) / dialectic strength

 1 MΩ / 200 V DC

 Coupling capacity (housing - power) / dielectric strength

 50 nF / 350 V AC

 Coupling capacity (electrode - power) / dielectric strength

 47 nF / 350 V AC

 Ambient temperature range:

 - 40 ... + 85 °C

 Protection

 type DLM-35_-_ _-C-_-_

 type DLM-35_-_ _-A(B,V,H)-_-_

 IP67

 IP68

 Maximum load resistance for current output (at U = 24 V)

 Rmax= 700 Ω

 Weight (excluding electrode

 and cable)

 performance N

 performance NT

 approx. 0.3 kg

 approx. 0.6 kg

 Cable (version with cable glands)

 PVC 2 x 0.75 mm2 or

 3x0.5 mm2 (according to variant)
