Technical specifications

 Work environment

 explosion-free area

 Supply voltage

 18 ... 36 V DC

 Output type

 current 4-20 mA with HART communication (limit values 3.9-20.5 mA)

 Current consumption

 4-20 mA / max. 22 mA

 Measurement error

 3mm (distance 1m to 20m) 10mm (distance 0,3m to 1m)

 Maximum range

 20m

 Dead Zone

 30cm

 Function principle

 FMCW

 Operating temperature range

 -30 to +70°C

 Measurement frequency

 3 level

 Measurement sensitivity

 Removal of false reflections from the interior of the tank

 Damping

 1 to 99s

 Status signaling

 adjustable 3,75 mA, 4 mA, 20 mA, 22 mA, NO CHANGE

 The time of the first measurement from the start of power supply

 20 s

 Separation capacity "power leads - housing"

 4nF / 500 VAC

 Maximum load resistance at

 U=24V

 U-22V

 U=20V

 R=270 Ω*

 R=180 ​Ω

 R=90 Ω

 Protection class

 IP 67

 Recommended cable

 PVC 2x0, 75mm2 with a diameter of 6-8 mm

 Tightening torque of the cable gland

 3 Nm

 Weight

 cca 0,5 kg
