Measurement

 Signal / Interface & Supply

 Pressure

 Analog output (for 4 ... 20 mA type)

 Accuracy

 ±0.5 % F.S

 Signal

 4 ... 20 mA, (2-wire loop powered)

 Measuring range

 0 ... 4.0 MPa

 Load

 Max. 250 Ohm

 Response time (t90)

 ≤1 ms (@ 90 % F.S)

 Fieldbus (for Modbus/RTU type)

 Protocol

 Modbus/RTU

 BUS-Length

 ≤ 1000 m

 Supply

 Voltage supply

 11 ... 36 VDC

 Current consumption

 Max. 20 mA

 Data interface

 Connection

 M12 Connector

 General data

 Material

 Process connection

 Stainless steel 1.4301

 Housing

 Stainless steel 1.4301

 Metal parts

 Stainless steel 1.4301

 Miscellaneous

 Electrical connection

 M12 Connector

 Protection class

 IP67

 Approvals

 CE

 Process connection

 G1/4” (ISO 228/1)

 Operating conditions

 Medium temperature

 Storage temperature

 -40 ... +125 °C
